Description
Good quality, clear communication, comfortable and durable. Flying with this low cost aviation headset, which is also great for passengers, you would entirely enjoy full-spectrum noise attenuation and reduction, comfortable fit and clear sound. An innovative aviation communication headset designed for the excellent challenges pilots of all types of aircraft face.
Molded cord assembly made to exceptional pull and flex standards
Noise-canceling microphone
Strong steel boom provides flexibility and steady microphone placement
Straight cord from headset to molded plug, 150CM
Colour: Black
Noise Reduction Ratings (NRR): 24dB
Specifications
Type: Dynamic (F40)
Frequency Response:100Hz to 8 kHz
Sensitivity:95+/-5 dB SPL
(1 kHz, 1 mW input per earcup side)
full volume on ear simulator
Impedance:150 ohms (300 ohms each; wired in parallel)
Rate Input:100mW
Max. Input: 250mW
Microphone and Amplifier:
Element Type: Noise-canceling
Frequency Response:100Hz to 5 kHz
Operating Voltage (supplied by aircraft ):8-32 Volts DC
Matching Impedance: 150-1000 ohms
Sensitivity:-33+/-4 dB
(ref: 0dB SPL=20.0uPa at 1 kHz with 10 Vdc 150 ohms AC load)
Operating Temperature: -20 to 70°C
Cordage: Straight cord from headset to molded plug, 150CM
Intercom Connections Plug:
Earphone Plug: PJ-055( .25″F6.3 phone plug)
Microphone Plug:PJ-068( .206″F5.2 phone plug)
Golden plated connectors
Headset size range Height: 10 to 14 cm
Color: Black
Boom: Flexible boom
1. Super comfortable for extended use, allowing you to enjoy longer flights in comfort.
2. Amplified electric noise canceling microphone.
3. Enhanced high fidelity sound speaker system for crystal clear communication.
4. Volume knob
5. G/A Dual Plugs or Helicopter U174 Single Plug
